Mobile oil station is designed for the transport, pumping, replacement, and refill of oil in the components and units of vehicles, tractors, sundry transport mechanisms, and maintenance/service stations.
MOBILE OIL-STATION SPECIFICATIONS: BASIC CONFIGURATION
|
 |
Number of seats
|
0 to 7
|
Drop-side platform, type
|
Open drop-side platform / drop-side platform with cover/ closed drop-side platform
|
Van body
|
With / without side slopes
With / without compartment
With / without drop-side platform
|
Production technology
|
Isothermal van body with S=60 mm thick panels Frameless, made of sandwich panels
Styropen insulation is a polystyrene material that has a density of 50 kg/m3 and a thermal conductivity of 0.0343 W/m*K. A plywood layer between the heat insulation and the facing reinforces the entire structure.
|
Outer and inner facing
|
Galvanized sheets with polymer coating (plated steel) / reinforced fiberglass
|
Packaging includes
|
1. Isothermal body van S=60 mm.
2. Spare-wheel carrier on the rear overhang of the frame
3. Надрамник
3. Subframe
4. Hot-air gun
5. Sink (basin) for repair personnel 6. Diesel-generator compartment with a console and a maintenance ladder. 7. Compartment for oil-dispensing nozzles with a pump-control unit 8. Side door to access the equipment maintenance and tank refill compartment 9. Rear double door 10. Double-glazed windows with leaves 11. Ladder 12. Planar auxiliary heater 13. Roof-mounted fan 14. Spotlight-floodlight 15. External power supply 16. Generator with a maintenance hatch 17. Barrel with an electric pump to pump consistent lubricants on a pallet 18. Tank for hydraulic oil (heated) 19. Tank for waste oils
20. Tank for transmission oil; has two heating elements for oil heating 21. Coolant tank
|
22. Motor-oil tank with oil-heating elements 23. Pumping unit
24. Oil-dispensing reel with dispensing nozzles and flow meters
25. Reel for dispensing consistent lubrication; has a dispensing nozzle and a flow meter. 26. Electric cabinet 27. Diesel power plant 28. Socket 29. Compressor 30. Oil and hydraulic-fluid purification unit 31. Local light 32. Rotary console with a movable manual hoist 33. Toolbox with tools 34. Fire extinguisher 35. Entrenching tool 36. Chassis accessories 37. Electrical-safety accessories and tools
38. Car wash
38. Water tank
40. Welding inverter, welding current
41. Manual drill
42. Angle grinder
43. Jib crane
44. Vertical drilling machine, grinder, etc.
|
ADDITIONAL OPTIONS
|
- Various configuration options
- Rooftop spotlight for repair-facility illumination at night.
- Heater
- Air conditioning
- Car stereo
- Any loader crane upon request
- Tail lifts
- PTO-driven winch
- Additional doors and windows
- Sundry necessary equipment
|
MOBILE OIL-STATION SPECIFICATIONS: BASIC CONFIGURATION
|
 |
Positioning
|
Mounted in the vehicle's drop-side platform. Dismountable.
|
Packaging includes
|
1. Oil station frame
2. 200-liter oil tank
3. 1,000-liter waste-oil tank
4. 1,000-liter water tank
5. MARINA 24V-G20 pump
6. BE-G bypass valve (Rover Pompe)
7. Open oil-hose reel
8. Self 2000 PIUSI dispensing valve
|
9. PIUSI F00490020 mechanical oil meter
10. Check valve with a mesh (mounted inside 200-liter tanks)
11. Remote control
12. ДУ-20 hydraulic connecting hoses
13. ДУ-20 ball valves
14. Power cable
|
ADDITIONAL OPTIONS
|
- Various configuration options
- Heater
- Air conditioning
- Car stereo
- PTO-driven winch
- Sundry necessary equipment
|
*Technical specifications are presented on this page for reference only, as the parameters and other operational indicators depend on the vehicle configuration of choice.
