Sand spreaders

Special materials and reagents are spread all over sidewalks and roadways to create an anti-slipping effect; the equipment used for that purpose is referred to as sand spreaders. These devices spread anti-icing agents quickly and safely, helping save time and human resources.

This equipment can be mounted both in a dump-truck body or on a chassis frame. There are two ways to mount a sand spreader in a dump-truck body: one implies using lifting devices, the other one does not. Adjustable spread width and height of the spreading disk make sand spreaders truly versatile, as a single device can be used to treat roads of various types. It can be efficiently used not only within city limits, but in the countryside as well.

SAND-SPREADER SPECIFICATIONS: BASIC CONFIGURATION
Implementation	On chassis frame / in a dump-truck body
Hopper capacity, m³	3 to 16
Sand-spreading density, g/m²:	50…500
Sand-spreading density adjustment step, g/m²	Stepless adjustment
Adjustable spreading width, m	2 - 12
Width adjustment step, m	Stepless adjustment
Transporter	Double-row scraper transporter with an anchor chain
Hopper implementation	Anti-corrosion inner coating / stainless steel
Spreading disk diameter, mm	500
Type	with or without retractable legs
Spreading disk implementation	stainless steel
Bunker wall heating	Exhaust heating / no heating
PTO for the sand spreader	driven by an independent engine or by the chassis
Operating speed, km/h	Up to 50
ADDITIONAL OPTIONS
EV-9OS electric vibrator	This device helps reliably discharge wet or frozen materials from sand-spreader hoppers or dump-truck bodies. This is a special vehicle vibrator series designed for continuous heavy-duty operation
Rated power consumption, kW	0.5
Rated voltage, V	24
Rated current frequency, Hz	50
Synchronous oscillation frequency, Hz	50
Static moment, kgfcm	2,55…5,1
Driving force at idle oscillation frequency, kN	1,9…3,9
Dimensions, mm	300х180х200
Connecting dimensions, mm	100х145
Weight, kg	22,0

*Technical specifications are presented on this page for reference only, as the parameters and other operational indicators depend on the vehicle configuration of choice.
